$199.00

Moving magnet, elliptical stylus, aluminum cantilever, and 4.0-mV output.

SKU: aad-Sumiko Olympia Category: Tags: ,
Description

Description

The Olympia brings another level of acoustic refinement to the mix with an upgraded stylus and cantilever assembly, allowing for more dynamic punch and improved frequency response during playback. Due to its improved tracking capabilities, the Olympia is an excellent return on investment when upgrading from the Rainier cartridge, and can even be upgraded to the capable Moonstone stylus further on down the line.

TECHNICAL SPECIFICATIONS

Cartridge Type:
Moving Magnet

Stylus:
0.3 x 0.7 micron Elliptical

Cantilever Material:
aluminum

Wire Material:
copper

Internal Impedance:
1,130Ω

Load Impedance:
47kΩ

Frequency Response:
12Hz – 30kHz

Output Voltage:
4mV @ 1kHz

Channel Separation:
30dB @ 1kHz

Channel Balance:
1.5dB @ 1kHz

Compliance:
12×10-6 cm/dyn @ 100Hz

Recommended Load Capacitance:
100pF – 200pF

Vertical Tracking Angle:
20°

Tracking Force:
1.8g – 2.2g

Recommended Force:
2.0g

Cartridge Weight:
6.5g

Replacement Stylus Unit:
RS Olympia
RS Moonstone
RS Rainier

Brand

Brand

Sumiko

Additional information

Additional information

Weight 1 lbs
Dimensions 3 × 3 × 3 in
