$4,999.95

SKU: aah-soundsmith-Sussurro mk II Category: Tags: ,
Description

Description

The Sussurro ~ critical design decisions, realized. Lowest internal mass. Best damping. Esoteric stylus and cantilever. If you need to stay in constant contact, your cartridge has arrived.

Inspired by Frank Schröder, designed and individually hand made by Peter Ledermann, Soundsmith’s Sussurro is a cartridge designed to specifically address the most intricate and critical issues of cartridge design. The new MKII Sussurro has a newly designed moving iron element to reduce moving mass by 70%; extremely low stored energy, the new MKII damping system and an innovative energy distribution path to effectively transfer mechanical energy away from the cantilever through the cartridge body into the tone arm. So what does all this mean??

Low jitter. Jitter? You probably thought that was a term reserved for digital systems. Not so. Stylus jitter is responsible for loss of detail, and making a cartridge sound, well, like a cartridge. The Sussurro stays in constant contact with the record groove. If you are not in constant contact, you can’t hear what has truly been recorded.

Also available in dual-coil mono.

Specifications

Cartridge Type: Fixed Coil

Stylus Type: O.C. Contact Line

Output: Low

Output Voltage: ,4mV

Available As Dual Coil Mono: Yes

Additional Specifications

Stylus: Contact Line Nude, 0.100mm SQ
Radius of curvature: OCL (Optimized Contour Contact Line) SELECTED
Cantilever: Ruby
Recommended tracking force: 1.8 to 2.2 grams
Effective tip mass: 0.30 mg
Compliance: 10μm/mN (low compliance)
Frequency response: 20-20,000 Hz ± 1.0 dB
Channel separation (stereo only): 1000 Hz >34 dB, 50-15,000 >25 dB
Channel difference: Output Voltage: ≥0.4 mV
DC Resistance (DCR): 10-11 Ω each channel
Coil: 2.75 mH each channel
Suggested Preamp Gain: 58-64 dB
Soundsmith Recommends: MCP2 Variable Loading Preamp
Cartridge weight: 10.25 grams
Stylus to Mounting Hole Offset: ≈ 10mm (0.4″)
Loading: ≥ 470 Ω

Brand

Brand

Soundsmith

Soundsmith has designed and manufactured – and repaired – varied types of audio equipment for over 35 years. Dedicated to producing the world’s most accurate vinyl sound reproduction, Soundsmith recently introduced its new top-of-the line moving Iron cartridge, the VOICE, which is touted as Soundsmith’s best sounding MM-preamp cartridge yet. As the nationally recognized leader in the field of high-end audio, home theater and home electronics, Overture is proud to include Soundsmith in our presentation of high-performance components. If you are interested in purchasing a Soundsmith product, you can trade-in any other brand electronic component or speaker on it by filling out Overture’s Trade-In Form.
