$1,999.95

SKU: aad-soundsmith-Zephyr MIMC Star Category: Tags: ,
Description

Description

Specifications

Cartridge Type: Fixed Coil

Stylus Type: Contact Line

Output: Low

Output Voltage: .4 mV

Available As Dual Coil Mono: Yes

Additional Specifications

Stylus: Selected Contact Line low mass Nude Stylus
Radius of curvature: 6 x 17 μm
Cantilever:Laser Drilled Sapphire
Recommended tracking force: 1.8 to 2.2 grams
Effective tip mass: 0.32 mg
Compliance: 10 μm/mN (low compliance)
Frequency response: 15-45,000 Hz ± 2.0 dB
Channel separation (stereo only): 1000 Hz >28 dB, 50-15,000 >25 dB
Channel difference: Output Voltage: ≥0.4 mV
DC Resistance (DCR): 10-11 Ω each channel
Coil: 2.75 mH each channel
Suggested Preamp Gain: 58-64 dB
Soundsmith Recommends: MCP2 Variable Loading Preamp
Cartridge weight: 10.25 grams
Stylus to Mounting Hole Offset: ≈ 10mm (0.4″)
Loading: ≥ 470 Ω

Brand

Brand

Soundsmith

Soundsmith has designed and manufactured – and repaired – varied types of audio equipment for over 35 years. Dedicated to producing the world’s most accurate vinyl sound reproduction, Soundsmith recently introduced its new top-of-the line moving Iron cartridge, the VOICE, which is touted as Soundsmith’s best sounding MM-preamp cartridge yet. As the nationally recognized leader in the field of high-end audio, home theater and home electronics, Overture is proud to include Soundsmith in our presentation of high-performance components. If you are interested in purchasing a Soundsmith product, you can trade-in any other brand electronic component or speaker on it by filling out Overture’s Trade-In Form.
